dr-5901002electric chain hoist
Features
Specifications
| Item NO. | Capacity(t) | Lifting Speed(m/min) | Lifting motor power(kw) | Running speed(m/min) | Run the motor power(kw) | No.of chiain | Chain Size(mm) | I-beam orbit(mm) | Power voltage |
| DR-290100200 | 0.5 | 7.2 | 1.1 | 12 | 0.4 | 1 | 6.3*19 | 72-125 | 3p 220-460v 50/60Hz |
| DR-290100201 | 1 | 6.8 | 1.5 | 11、21 | 0.4 | 1 | 7.1*21 | 68-153 | |
| DR-290100202 | 1 | 3.6 | 1.1 | 11、21 | 0.4 | 2 | 6.3*19 | 68-153 | |
| DR-290100203 | 2 | 6.6 | 30 | 11、21 | 0.4 | 1 | 10*30 | 82-178 | |
| DR-290100204 | 2 | 3.4 | 1.5 | 11、21 | 0.4 | 2 | 7.1*21 | 82-178 | |
| DR-290100205 | 3 | 6.6 | 30 | 11、21 | 0.75 | 1 | 11.2*34 | 100-178 | |
| DR-290100206 | 3 | 3.4 | 1.5 | 11、21 | 0.75 | 2 | 10*30 | 100-178 | |
| DR-290100207 | 3 | 2.2 | 1.5 | 11、21 | 0.75 | 3 | 7.1*21 | 100-178 | |
| DR-290100208 | 5 | 2.8 | 3.0 | 11、21 | 0.75 | 2 | 11.2*34 | 112-178 | |
| DR-290100209 | 7.5 | 1.8 | 3.0 | 11、21 | 0.75 | 3 | 11.2*34 | 112-178 | |
| DR-290100210 | 10 | 3.8 | 3.0*2 | 11、21 | 0.75*2 | 4 | 11.2*34 | 150-220 | |
| DR-290100211 | 15 | 1.8 | 3.0*2 | 11、21 | 0.75*2 | 6 | 11.2*34 | 150-220 | |
| DR-290100212 | 20 | 1.4 | 3.0*2 | 11、21 | 0.75*2 | 8 | 11.2*34 | 150-220 | |
| DR-290100213 | 25 | 1.1 | 3.0*2 | 11、21 | 0.75*2 | 8 | 11.2*34 | 150-220 |
